UniFi Wi-Fi 6 PRO AP 4x4 Mu-/Mimo Wi-Fi 6, 2.4GHz @ 573.5 Mbps & 5GHz @ 4.8Gbps

U6-PRO

$319.95
In Stock

UniFi Wi-Fi 6 PRO AP 4x4 Mu-/Mimo Wi-Fi 6, 2.4GHz @ 573.5 Mbps & 5GHz @ 4.8Gbps



Indoor, dual-band WiFi 6 access point that can support over 300 clients with its 5.3 Gbps aggregate throughput rate.

The Access Point WiFi 6 Pro (U6 Pro) is a high-performance, dual-band WiFi 6 access pointideal for home and office use. The U6 Pro is capable of reaching an aggregate throughput rate up to 5.3 Gbps with its 5 GHz (4x4 MIMO) and 2.4 GHz (2x2 MIMO) bands, which allows it to support over 300 concurrently connected clients while maintaining an even, reliable wireless experience across your entire network. It can also isolate your guest traffic to ensure optimal security and speed.



The U6 Pro also operates at full 4x4 MIMO with 160 MHz channels to create high-capacity wireless uplinks and facilitate faster data transfer. It can be set up in minutes and fully managed with the UniFi Network application*.

*Managed with the: Dream MachinePro: Version1.9.0-12andlater
UniFi Networkapplication: Version6.1.56 and later

Features:
Dual-band WiFi 6 (802.11ax)
5 GHz (4x4 MU-MIMO and OFDMA) band with a 4.8 Gbps throughput rate
2.4 GHz (2x2 MU-MIMO and OFDMA) band with a 573.5 Mbps throughput rate
Gigabit Ethernet, powered with 802.3af PoE (PoE injector Sold Separately Here)
Operates at full 4x4 MIMO with 160 MHz bandwidth
300+ concurrent client capacity
Guest Traffic Isolation, which enhances wireless network security and lowers traffic congestion



*PoE NOT Included (Sold Separately)



UniFi Wireless AP Skins

UniFi WiFi6 Improved Performance

Easily set up and grow your UniFi network

(U6-Pro)

UniFi Wi-Fi 6 PRO Access Point

Pack Includes:

  • 1 x UniFi U6-PRO
  • 1 x Cable Gromet
  • 1 x Mountling Template
  • 1 x Mounting Plate
  • 1 x Ceiling Backing Plate
  • 4 x Plate Ceiling Screws
  • 4 x Wall Screws
  • 4 x Keps Nuts
  • 4 x Screw Anchors
  • 2 x Locking knobs
  • 2 x Locking Screws
  • 1 x Hex Key large
  • 1 x Hex Key Small
  • Quick Start Guide

*PoE NOT Included (Sold Separately)

UniFi Wi-Fi 6 PRO Access Point - Specifications

Mechanical
Dimensions Ø197 x 35 mm (Ø7.76 x 1.38")
Weight Without mount: 460 g (1.01 lb)
With mount: 600 g (1.32 lb)
Enclosure material Plastic
Mounting material SGCC steel
Weatherproofing IP54
Hardware
Management interfaces Ethernet
Bluetooth
Networking interface (1) GbE RJ45 port
Button Factory reset
LEDs White/Blue
Power method 802.3at PoE+
Power supply UniFi PoE switch
48V, 0.5A PoE adapter (not included)
Supported voltage range 44 to 57VDC
Max. power consumption 13W
Max. TX power
2.4 GHz
5 GHz

22 dBm
26 dBm
MIMO
2.4 GHz
5 GHz

2 x 2 (UL MU-MIMO)
4 x 4 (DL/UL MU-MIMO)
Throughput rate
2.4 GHz
5 GHz

573.5 Mbps
4.8 Gbps
Antenna gain
2.4 GHz
5 GHz

4 dBi
6 dBi
Mounting Wall/ceiling (included)
Operating temperature -30 to 60° C (-22 to 140° F)
Operating humidity 5 - 95% noncondensing
Certifications CE, FCC, IC
Software
WiFi standards 802.11a/b/g
WiFi 4/WiFi 5/WiFi 6
Wireless security WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)
BSSID 8 per radio
VLAN 802.1Q
Advanced QoS Per-user rate limiting
Guest traffic isolation Supported
Concurrent clients 300+
Zero wait DFS Yes*
*Supported with upcoming firmware versions
Supported Data Rates
802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b 1, 2, 5.5, 11 Mbps
802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n (WiFi 4) 6.5 Mbps to 600 Mbps (MCS0 - MCS31, HT 20/40)
802.11ac (WiFi 5) 6.5 Mbps to 3.4 Gbps (MCS0 - MCS9 NSS1/2/3/4, VHT 20/40/80/160)
802.11ax (WiFi 6) 7.3 Mbps to 4.8 Gbps (MCS0 - MCS11 NSS1/2/3/4, HE 20/40/80/160)
SKU U6-Pro
Model # U6-PRO
Barcode # 810010076830
Brand Ubiquiti
Shipping Weight 0.4000kg
Shipping Width 0.180m
Shipping Height 0.092m
Shipping Length 0.210m
Shipping Cubic 0.003478000m3
Unit Of Measure ea
