Fiber-to-Ethernet Converter


In Stock

Fiber-to-Ethernet Converter


UFiber Active Ethernet allows for easy media conversion from fiber to copper. It supports 1 Gbps fiber uplink speeds and 10/100/1000 Ethernet speeds. UFiber Active Ethernet can be powered with 24V Passive PoE or 802.3af and is compatible with all UFiber SFP Modules (power supply and SFP modules not included).

Fiber Optic Data Transfer
Using fiber optic cable for data transport significantly reduces electrostatic discharge (ESD) failures and electromagnetic interference (EMI). Data integrity is also sustained in runs beyond 100 meters, the limit of Ethernet over twisted-pair cable. The UF-AE delivers data over long distances at high speed using fiber. The UF-AE provides fiber connectivity to an RJ45 Ethernet device, which in turn provides 802.3af or 24V passive PoE to the UF-AE.

Module Compatibility
The versatile UF-AE connects any SFP or SFP+ module at the maximum speed of 1 Gbps. All UFiber SFP or SFP+ modules are supported. For more information, go to:

PoE Convenience
The UF-AE is powered by 24VDC passive PoE or 802.3af active PoE.

Supported Speeds
1 Gbps fiber uplink speeds and 10/100/1000 Ethernet speeds are supported.

Status LEDs
Intuitive LEDs indicate link and speed status.

Indoor Installation
Use the included bracket to easily mount the UF-AE on a wall.


Fiber-to-Ethernet Converter


Pack Includes:

  • 1 x UFiber ActiveEthernet
  • 1 x Wall Mount Bracket
  • 4 x Screws
  • 4 x Screw Anchors
  • Quick Start Guide

*POE Adapter Sold Separately

Fiber-to-Ethernet Converter - Specifications



76.5 x 76.5 x 26.4 mm
(3.01 x 3.01 x 1.04")


68 g (2.40 oz)

Networking Interfaces

(1) 1 Gbps SFP Port

(1) 10/100/1000 Mbps RJ45 Port

Power Method

802.3af PoE: (Pins 1, 2+; 3, 6-)

24V Passive PoE: (Pins 4, 5+; 7, 8-)

Power Supply

802.3af PoE or 24V Passive PoE Device*

Max. Power Consumption


Supported Voltage Range

16 to 57V


(1) Ethernet

(1) Optical Signal

(1) Power

Operating Temperature

-40 to 60° C (-40 to 140° F)

Operating Humidity

10 to 90% Noncondensing

ESD/EMP Protection

± 12kV Contact/Air



* Power supply not included.


Shipping Specifications

Model # UF-AE
Barcode # 817882026734
Brand Ubiquiti
Shipping Weight 0.0700kg
Shipping Width 0.077m
Shipping Height 0.027m
Shipping Length 0.077m
Shipping Cubic 0.000160000m3
Unit Of Measure ea
