UniFi 8-Port 60W Managed Gigabit Switch 4-Ports PoE
US-8-60W
$270.66
In Stock
8-Port Managed Gigabit Switches
The US-8-60W is an 8-port gigabit switch with four 802.3af PoE ports. Its auto-sensing PoE ports deliver up to 15.4W of power per port. The new 8-port models feature Gigabit Ethernet ports in a compact form factor.
For its total, non-blocking throughput, each UniFi Switch supports up to 8 Gbps and offers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss, with a switching capacity of 16 Gbps.
(US-8-60W)
UniFi Switch 8 60W
Package Includes
- 1 x UniFi Switch 8 60W
- 2 x Mounting Screws
- 2 x Screw Anchors
- 1 x Power Adapter
- 1 x Power Cord
- Quick Start Guide
UniFi Switch 8 60W - Specifications
| UNIFI SWITCH US-8-60W | |
|---|---|
| Dimensions | 148.0 x 99.5 x 30.7 mm (5.83 x 3.92 x 1.21") |
| Weight | 432 g (15.24 oz) |
| Enclosure Characteristics | SGCC Steel |
| Total Non-Blocking Throughput | 8 Gbps |
| Switching Capacity | 16 Gbps |
| Forwarding Rate | 11.9 Mpps |
| Max. Power Consumption | 12W (Excluding PoE Output) |
| Max. PoE Wattage per Port | 15.4W |
| Power Method | 48VDC, Max. 2A |
| Supported Voltage Range | 57VDC to 44VDC |
| Power Supply | External AC/DC Adapter, 48V, 1.25A |
| LEDs | PoE (Port 8), Speed/Link/Activity (All Ports) |
| Networking Interfaces | (8) 10/100/1000 Mbps RJ45 Ports |
| PoE Interfaces | (4) Ports 5, 6, 7, 8; IEEE802.3af |
| ESD/EMP Protection | Air: ± 24 kV, Contact: ± 24 kV |
| Operating Temperature | -5 to 45° C (23 to 113° F) |
| Operating Humidity | 5 to 95% Noncondensing |
| Shock and Vibration | ETSI300-019-1.4 Standard |
| Certifications | CE, FCC, IC |
Shipping Specifications
| SKU | US-8-60W |
| Model # | US-8-60W |
| Barcode # | 817882023009 |
| Brand | Ubiquiti |
| Shipping Weight | 1.0800kg |
| Shipping Width | 0.135m |
| Shipping Height | 0.085m |
| Shipping Length | 0.225m |
| Shipping Cubic | 0.002582000m3 |
| Unit Of Measure | ea |
UniFi Switch 8 60W - Documents
UniFi Switch US-8-60W DatasheetBe The First To Review This Product!
