UniFi Dome Camera Weatherproof (IPx4) Ubiquiti
UVC-G4-DOME
UniFi Dome Camera Weatherproof (IPx4) Ubiquiti
4MP, weather and vandal-proof dome camera with infrared LEDs for clear, around-the-clock surveillance.
The G4 Dome is a durable, outdoor-ready dome camera that captures 4MP video at 24 frames per second (FPS) and provides consistently clear nighttime surveillance with its built-in infrared LEDs. The G4 Dome is also protected with an IPX4-rated, weatherproof enclosure with IK08-rated vandal resistance, making it a great choice for monitoring highly populated areas and venues. Designed for optimal versatility, the compact G4 Dome can be discreetly mounted to either a wall or ceiling, and depending on its orientation, you can easily pan or tilt its lens to ensure the right view.
Features:
Managed with the UniFi Protect application and mobile app.
Camera Features
- 4MP, 24 FPS video
- Integrated infrared LEDs for nighttime surveillance
- IPX4-rated weatherproof enclosure
- IK08-rated vandal resistance
- Built-in microphone
- Powered by 802.3af PoE
*POE Adapter Sold Separately (See U-POE-AF 48V Gigabit 802.3af )
UniFi Protect Software

Manage Cameras with All-New Cloud Key Gen2 Plus
Designed for easy setup and rapid deployment, the Cloud Key Gen2 Plus is a compact, plug-and-play solution for managing your cameras. Record up to 1600 hours of footage with the included 1 TB hard drive, or upgrade the hard drive to store even more video.

UniFi Protect Cameras Comparison
Compare all of UniFi cameras and choose the best for your needs.
(UVC-G4-DOME)
UniFi Dome Camera Weatherproof (IPx4) Ubiquiti
Pack Includes:
- 1 x UniFi Dome Camera Weatherproof (IPx4) Ubiquiti (UVC-G4-DOME)
- 1 x Tightening Tool Key
- 4 x Screw Anchors
- 4 x Self-Tapping Screws
- 1 x Ceiling Mount Bracket
- 4 x Machine Screws
- 1 x Quick Start Guide
*POE Adapter Sold Separately (See U-POE-AF 48V Gigabit 802.3af)
UniFi Dome Camera Weatherproof (IPx4) Ubiquiti - Specifications
| Mechanical | |
|---|---|
| Dimensions |
Ø109.2 x 64.5 mm (Ø4.3 x 2.5") |
| Weight |
Without mount: 370 g (13.05 oz) With mount: 390 g (13.76 oz) |
| Enclosure materials |
Aluminum alloy, polycarbonate, hard-coated dome |
| Mounting materials |
Polycarbonate, stainless steel |
| Weatherproofing |
IPX4 |
| Resistance |
IK08 |
| Optics | |
| Sensor |
4 MP CMOS sensor |
| Lens |
Fixed focal length |
| View angle |
H:102.4°, V:71.4°, D:134.3° |
| Night mode |
Built-in light sensor Built-in IR LED illumination and IR cut filter |
| Video | |
| Video compression |
H.264 |
| Resolution |
2688 x 1512 (16:9) |
| Maximum frame rate |
24 FPS |
| Image settings |
Brightness, contrast, sharpness, saturation, noise reduction, |
| System | |
| Processor specs |
ARM® quad-core Cortex™-A53 |
| Memory information |
512 MB |
| Management interface |
UniFi Protect |
| Networking interface |
GbE RJ45 port |
| Flash memory support |
256 MB |
| Max. power consumption |
5W |
| Power method |
802.3af PoE |
| Supported voltage range |
44 to 57VDC |
| Link/activity LED |
Yes |
| Button |
Factory reset |
| Operating temperature |
-20 to 40° C (-4 to 104° F) |
| Operating humidity |
0 to 90% noncondensing |
| Certifications |
FCC, IC, CE |
SHIPPING SPECIFICATIONS
| SKU | UVC-G4-DOME |
| Model # | UVC-G4-DOME |
| Barcode # | 810010073013 |
| Brand | Ubiquiti |
| Shipping Weight | 0.8200kg |
| Shipping Width | 0.110m |
| Shipping Height | 0.130m |
| Shipping Length | 0.182m |
| Shipping Cubic | 0.002603000m3 |
| Unit Of Measure | ea |
